AtomStack X70 Max vs Ikier K2 Pro 55W
What X70 Max does better (4) and where K2 Pro 55W wins (3) — every spec side by side.
vs
9.6Power & cutting9.5
6.1Speed8.0
3.7Precision4.4
9.7Work area7.4
6.4Safety8.7
8.4Features & ease of use8.9
Dimensions
Size comparison
X70 MaxK2 Pro 55W
| X70 Max | K2 Pro 55W | Difference | |
|---|---|---|---|
| Height | 230 mm | 261 mm | −31 mm |
| Width | 1,056 mm | 750 mm | +306 mm |
| Depth | 1,168 mm | 600 mm | +568 mm |
Drawn to the same scale from the official dimensions (front and side).
Why is X70 Max better than K2 Pro 55W?
- Work area (surface)6,800 cm² vs 1,600 cm²4.2×
- Laser output power77 W vs 55 W+40%
- Work area depth (Y)850 mm vs 320 mm2.7×
- Work area width (X)800 mm vs 500 mm+60%
Why is K2 Pro 55W better than X70 Max?
- Enclosed (fully covered)No · X70 Max: Yes
- Laser spot size0.18 mm vs 0.1 mm+80%
- Max engraving / travel speed400 mm/s vs 600 mm/s+50%
Specifications
Side by side
| General | ||
| Laser sources | Blue diode (≈455 nm) | Blue diode (≈455 nm) |
| Motion system | Gantry (XY rails) | Gantry (XY rails) |
| Two laser sources | No | No |
| Laser power | ||
| Laser output power | 77 W | 55 W |
| Work area | ||
| Work area | 800 × 850 mm | 500 × 320 mm |
| Work area width (X) | 800 mm | 500 mm |
| Work area depth (Y) | 850 mm | 320 mm |
| Work area (surface) | 6,800 cm² | 1,600 cm² |
| Conveyor / roll feeder support | — | Yes |
| Speed & cutting | ||
| Max engraving / travel speed | 400 mm/s | 600 mm/s |
| Max cutting depth – acrylic | 25 mm | — |
| Precision | ||
| Laser spot size | 0.18 mm | 0.1 mm |
| Positioning accuracy | 0.01 mm | — |
| Safety | ||
| Enclosed (fully covered) | No | Yes |
| Laser safety class | — | Class 1 (eye-safe, enclosed) |
| Flame / fire detection | Yes | Yes |
| Tilt / movement sensor | — | Yes |
| Lid interlock | — | Yes |
| Exhaust fan | — | Yes |
| Features | ||
| Air assist | Yes | Yes |
| Built-in camera | No | No |
| Autofocus / auto height | Yes | Yes |
| Rotary attachment support | — | Yes |
| Touchscreen / control panel | Yes | — |
| Offline engraving (no computer) | Yes | — |
| Connectivity & software | ||
| Connections | USB | USB, Wi-Fi |
| Wi-Fi | Yes | Yes |
| USB | Yes | Yes |
| Compatible software | LightBurn, LaserGRBL, AtomStack Studio | LightBurn, AtomStack Studio |
| LightBurn compatible | Yes | Yes |
| Size & power | ||
| Width | 1,056 mm | 750 mm |
| Depth | 1,168 mm | 600 mm |
| Height | 230 mm | 261 mm |
| Weight | — | 23.6 kg |
| Rated power consumption | 360 W | — |
| Input voltage | 100–240 V | — |
