AtomStack Swift vs Ortur H10 10W
What Swift does better (0) and where H10 10W wins (4) — every spec side by side.
Why is Swift better than H10 10W?
Swift has no measurable advantages in this pair.
Why is H10 10W better than Swift?
- Work area (surface)900 cm² vs 1,600 cm²+78%
- Laser output power7 W vs 10 W+43%
- Work area width (X)300 mm vs 400 mm+33%
- Work area depth (Y)300 mm vs 400 mm+33%
Specifications
Side by side
| General | ||
| Laser sources | Blue diode (≈455 nm) | Blue diode (≈455 nm) |
| Motion system | Gantry (XY rails) | Gantry (XY rails) |
| Two laser sources | No | No |
| Wavelength | — | 450 nm |
| Laser power | ||
| Laser output power | 7 W | 10 W |
| Work area | ||
| Work area | 300 × 300 mm | 400 × 400 mm |
| Work area width (X) | 300 mm | 400 mm |
| Work area depth (Y) | 300 mm | 400 mm |
| Work area (surface) | 900 cm² | 1,600 cm² |
| Work-area extension kit | Yes | — |
| Speed & cutting | ||
| Max engraving / travel speed | — | 333 mm/s |
| Max cutting depth – wood / plywood (one pass) | — | 12 mm |
| Max cutting depth – acrylic | — | 8 mm |
| Precision | ||
| Laser spot size | — | 0.08 mm |
| Positioning accuracy | — | 0.01 mm |
| Safety | ||
| Enclosed (fully covered) | No | No |
| Flame / fire detection | No | No |
| Emergency stop button | — | Yes |
| Tilt / movement sensor | — | Yes |
| Built-in fume filter / purifier | — | Yes |
| Laser shield / filter cover | — | Yes |
| Features | ||
| Air assist | Yes | Yes |
| Built-in camera | No | No |
| Autofocus / auto height | No | No |
| Rotary attachment support | Yes | Yes |
| Connectivity & software | ||
| Connections | — | USB |
| Wi-Fi | — | No |
| USB | — | Yes |
| Phone app control | — | Yes |
| Compatible software | LightBurn, AtomStack Studio | LightBurn, LaserGRBL |
| LightBurn compatible | Yes | Yes |
| Size & power | ||
| Weight | 2.8 kg | — |
