- S30 Ultra 33W vs S1 10W
Sculpfun S30 Ultra 33W vs xTool S1 10W
What S30 Ultra 33W does better (5) and where S1 10W wins (2) — every spec side by side.
vs
8.4Power & cutting5.7
6.7Precision8.2
9.4Work area8.4
5.6Safety9.3
Why is S30 Ultra 33W better than S1 10W?
- Laser output power33 W vs 10 W3.3×
- Work area (surface)3,510 cm² vs 1,643 cm²2.1×
- Positioning accuracy0.005 mm vs 0.01 mm2×
- Work area depth (Y)595 mm vs 330 mm+80%
- Work area width (X)590 mm vs 498 mm+18%
Why is S1 10W better than S30 Ultra 33W?
- Enclosed (fully covered)No · S30 Ultra 33W: Yes
- Laser spot size0.1 mm vs 0.06 mm+67%
Specifications
Side by side
| General | ||
| Laser sources | Blue diode (≈455 nm) | Blue diode (≈455 nm) |
| Motion system | Gantry (XY rails) | Gantry (XY rails) |
| Two laser sources | No | — |
| Wavelength | 455 nm | — |
| Frame material | Aluminium | — |
| Laser power | ||
| Laser output power | 33 W | 10 W |
| Work area | ||
| Work area | 590 × 595 mm | 498 × 330 mm |
| Work area width (X) | 590 mm | 498 mm |
| Work area depth (Y) | 595 mm | 330 mm |
| Work area (surface) | 3,510 cm² | 1,643 cm² |
| Max workpiece height | — | 134 mm |
| Work-area extension kit | Yes | — |
| Speed & cutting | ||
| Max engraving / travel speed | — | 400 mm/s |
| Precision | ||
| Laser spot size | 0.1 mm | 0.06 mm |
| Positioning accuracy | 0.005 mm | 0.01 mm |
| Linear rails | Yes | — |
| Safety | ||
| Enclosed (fully covered) | No | Yes |
| Laser safety class | — | Class 1 (eye-safe, enclosed) |
| Flame / fire detection | No | — |
| Emergency stop button | Yes | — |
| Laser shield / filter cover | Yes | — |
| Features | ||
| Air assist | Yes | — |
| Built-in camera | No | — |
| Autofocus / auto height | No | — |
| Connectivity & software | ||
| Connections | USB, Wi-Fi, Bluetooth | USB, Wi-Fi |
| Wi-Fi | Yes | Yes |
| USB | Yes | Yes |
| Bluetooth | Yes | — |
| Compatible software | LightBurn, LaserGRBL | LightBurn, xTool Creative Space |
| LightBurn compatible | Yes | Yes |
| File formats | — | SVG, DXF, JPG, PNG, BMP, TIF |
| Size & power | ||
| Width | — | 765 mm |
| Depth | — | 561 mm |
| Height | — | 183 mm |
| Weight | — | 20 kg |
