Ortur R1 5W vs Two Trees TS1 Mini
What R1 5W does better (2) and where TS1 Mini wins (1) — every spec side by side.
Dimensions
Size comparison
R1 5WTS1 Mini
| R1 5W | TS1 Mini | Difference | |
|---|---|---|---|
| Height | 140 mm | 167 mm | −27 mm |
| Width | 272 mm | 157 mm | +115 mm |
| Depth | 250 mm | 157 mm | +93 mm |
| Weight | 2.4 kg | 1 kg | +1.4 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is R1 5W better than TS1 Mini?
- Enclosed (fully covered)Yes · TS1 Mini: No
- Max engraving / travel speed83 mm/s vs 50 mm/s+66%
Why is TS1 Mini better than R1 5W?
- Weight2.4 kg vs 1 kg2.4×
Specifications
Side by side
| General | ||
| Laser sources | Blue diode (≈455 nm), Infrared diode (1064 nm) | Blue diode (≈455 nm) |
| Motion system | Gantry (XY rails) | Gantry (XY rails) |
| Two laser sources | No | No |
| Wavelength | 450 nm | — |
| Laser power | ||
| Laser output power | 5 W | — |
| Work area | ||
| Work area | 100 × 100 mm | — |
| Work area width (X) | 100 mm | — |
| Work area depth (Y) | 100 mm | — |
| Work area (surface) | 100 cm² | — |
| Speed & cutting | ||
| Max engraving / travel speed | 83 mm/s | 50 mm/s |
| Precision | ||
| Laser spot size | 0.11 mm | — |
| Positioning accuracy | — | 0.05 mm |
| Safety | ||
| Enclosed (fully covered) | Yes | No |
| Laser safety class | Class 1 (eye-safe, enclosed) | — |
| Flame / fire detection | No | No |
| Tilt / movement sensor | Yes | — |
| Features | ||
| Air assist | No | No |
| Built-in camera | No | No |
| Autofocus / auto height | No | No |
| Connectivity & software | ||
| Connections | USB | — |
| Wi-Fi | No | — |
| USB | Yes | — |
| Phone app control | Yes | — |
| Compatible software | — | LightBurn, LaserGRBL |
| LightBurn compatible | — | Yes |
| File formats | — | NC, G-code |
| Size & power | ||
| Width | 272 mm | 157 mm |
| Depth | 250 mm | 157 mm |
| Height | 140 mm | 167 mm |
| Weight | 2.4 kg | 1 kg |
| Input voltage | — | 100–240 V |
