LaserPecker LP2 vs Wainlux Z3
What LP2 does better (4) and where Z3 wins (0) — every spec side by side.
Why is LP2 better than Z3?
- Work area (surface)100 cm² vs 64 cm²+56%
- Laser output power5 W vs 4.5 W+11%
- Work area width (X)100 mm vs 80 mm+25%
- Work area depth (Y)100 mm vs 80 mm+25%
Why is Z3 better than LP2?
Z3 has no measurable advantages in this pair.
Specifications
Side by side
| General | ||
| Laser sources | Blue diode (≈455 nm) | Blue diode (≈455 nm) |
| Motion system | Galvo (scanning mirrors) | Gantry (XY rails) |
| Two laser sources | No | No |
| Wavelength | 450 nm | 455 nm |
| Laser power | ||
| Laser output power | 5 W | 4.5 W |
| Work area | ||
| Work area | 100 × 100 mm | 80 × 80 mm |
| Work area width (X) | 100 mm | 80 mm |
| Work area depth (Y) | 100 mm | 80 mm |
| Work area (surface) | 100 cm² | 64 cm² |
| Work-area extension kit | — | Yes |
| Speed & cutting | ||
| Max engraving / travel speed | 600 mm/s | 600 mm/s |
| Precision | ||
| Positioning accuracy | — | 0.05 mm |
| Safety | ||
| Enclosed (fully covered) | No | No |
| Flame / fire detection | No | No |
| Laser shield / filter cover | Yes | — |
| Features | ||
| Air assist | No | No |
| Built-in camera | No | No |
| Autofocus / auto height | No | No |
| Rotary attachment support | Yes | Yes |
| Connectivity & software | ||
| Connections | Bluetooth | SD / USB drive |
| Wi-Fi | No | — |
| Bluetooth | Yes | — |
| SD / TF card | — | Yes |
| Phone app control | Yes | — |
| Compatible software | LaserPecker App | — |
| File formats | JPG, SVG, PNG, BMP, G-code, DXF | — |
| Size & power | ||
| Width | — | 220 mm |
| Depth | — | 130 mm |
| Height | — | 220 mm |
| Weight | — | 2.4 kg |
