- Kortek 10W vs C1 Mini 6W
Genmitsu Kortek 10W vs Sculpfun C1 Mini 6W
What Kortek 10W does better (6) and where C1 Mini 6W wins (0) — every spec side by side.
vs
5.7Power & cutting4.1
4.2Work area3.5
8.3Safety3.2
7.4Features & ease of use2.7
Why is Kortek 10W better than C1 Mini 6W?
- Laser output power10 W vs 6 W+67%
- Enclosed (fully covered)Yes · C1 Mini 6W: No
- Work area (surface)300 cm² vs 195 cm²+54%
- Air assistYes · C1 Mini 6W: No
- Wi-FiYes · C1 Mini 6W: No
- Work area depth (Y)200 mm vs 130 mm+54%
Why is C1 Mini 6W better than Kortek 10W?
C1 Mini 6W has no measurable advantages in this pair.
Specifications
Side by side
| General | ||
| Laser sources | Blue diode (≈455 nm), Infrared diode (1064 nm) | Blue diode (≈455 nm) |
| Motion system | Gantry (XY rails) | Gantry (XY rails) |
| Two laser sources | No | No |
| Wavelength | 455 nm | — |
| Laser power | ||
| Laser output power | 10 W | 6 W |
| Work area | ||
| Work area | 150 × 200 mm | 150 × 130 mm |
| Work area width (X) | 150 mm | 150 mm |
| Work area depth (Y) | 200 mm | 130 mm |
| Work area (surface) | 300 cm² | 195 cm² |
| Max workpiece height | 60 mm | — |
| Speed & cutting | ||
| Max engraving / travel speed | 117 mm/s | — |
| Precision | ||
| Laser spot size | — | 0.04 mm |
| Safety | ||
| Enclosed (fully covered) | Yes | No |
| Laser safety class | Class 1 (eye-safe, enclosed) | — |
| Flame / fire detection | No | No |
| Laser shield / filter cover | Yes | — |
| Features | ||
| Air assist | Yes | No |
| Built-in camera | No | No |
| Autofocus / auto height | No | No |
| Rotary attachment support | Yes | Yes |
| Connectivity & software | ||
| Connections | USB, Wi-Fi | USB |
| Wi-Fi | Yes | No |
| USB | Yes | Yes |
| Phone app control | Yes | — |
| Compatible software | — | LightBurn, LaserGRBL |
| LightBurn compatible | — | Yes |
| Size & power | ||
| Width | — | 290 mm |
| Depth | — | 250 mm |
| Height | — | 140 mm |
| Weight | — | 1.1 kg |
| Rated power consumption | 60 W | — |
