FoxAlien LE-4040 5W vs SainSmart Jinsoku LE-1620 5.5W
What LE-4040 5W does better (3) and where Jinsoku LE-1620 5.5W wins (2) — every spec side by side.
vs
3.2Power & cutting3.8
6.7Work area4.2
3.2Safety6.4
2.2Features & ease of use3.4
Dimensions
Size comparison
LE-4040 5WJinsoku LE-1620 5.5W
| LE-4040 5W | Jinsoku LE-1620 5.5W | Difference | |
|---|---|---|---|
| Height | 230 mm | 160 mm | +70 mm |
| Width | 640 mm | 410 mm | +230 mm |
| Depth | 580 mm | 400 mm | +180 mm |
Drawn to the same scale from the official dimensions (front and side).
Why is LE-4040 5W better than Jinsoku LE-1620 5.5W?
- Work area (surface)1,600 cm² vs 320 cm²5×
- Work area depth (Y)400 mm vs 160 mm2.5×
- Work area width (X)400 mm vs 200 mm2×
Why is Jinsoku LE-1620 5.5W better than LE-4040 5W?
- Laser output power5 W vs 5.5 W+10%
- Flame / fire detectionNo · LE-4040 5W: Yes
Specifications
Side by side
| General | ||
| Laser sources | Blue diode (≈455 nm) | Blue diode (≈455 nm) |
| Motion system | Gantry (XY rails) | Gantry (XY rails) |
| Two laser sources | No | No |
| Laser power | ||
| Laser output power | 5 W | 5.5 W |
| Work area | ||
| Work area | 400 × 400 mm | 200 × 160 mm |
| Work area width (X) | 400 mm | 200 mm |
| Work area depth (Y) | 400 mm | 160 mm |
| Work area (surface) | 1,600 cm² | 320 cm² |
| Max workpiece height | 30 mm | — |
| Precision | ||
| Positioning accuracy | 0.1 mm | — |
| Safety | ||
| Enclosed (fully covered) | No | No |
| Flame / fire detection | No | Yes |
| Laser shield / filter cover | — | Yes |
| Features | ||
| Air assist | No | No |
| Built-in camera | No | No |
| Autofocus / auto height | No | No |
| Rotary attachment support | — | Yes |
| Connectivity & software | ||
| Connections | USB | — |
| Wi-Fi | No | — |
| USB | Yes | — |
| Compatible software | LightBurn, LaserGRBL, Candle | LightBurn, LaserGRBL |
| LightBurn compatible | Yes | Yes |
| Size & power | ||
| Width | 640 mm | 410 mm |
| Depth | 580 mm | 400 mm |
| Height | 230 mm | 160 mm |
