- GM 100W vs GT Split MOPA 200W
Cloudray GM 100W vs Monport GT Split MOPA 200W
What GM 100W does better (1) and where GT Split MOPA 200W wins (4) — every spec side by side.
vs
8.9Power & cutting9.6
8.6Speed4.9
3.0Work area5.1
4.7Safety4.7
5.6Features & ease of use5.6
Why is GM 100W better than GT Split MOPA 200W?
- Max engraving / travel speed15,000 mm/s vs 10,000 mm/s+50%
Why is GT Split MOPA 200W better than GM 100W?
- Laser output power100 W vs 200 W2×
- Work area (surface)121 cm² vs 225 cm²+86%
- Work area width (X)110 mm vs 150 mm+36%
- Work area depth (Y)110 mm vs 150 mm+36%
Specifications
Side by side
| General | ||
| Laser sources | Fibre (1064 nm) | Fibre (1064 nm) |
| Motion system | Galvo (scanning mirrors) | Galvo (scanning mirrors) |
| Two laser sources | No | No |
| MOPA fibre source (adjustable pulse) | Yes | Yes |
| Wavelength | 1,064 nm | 1,064 nm |
| Laser power | ||
| Laser output power | 100 W | 200 W |
| Work area | ||
| Work area | 110 × 110 mm | 150 × 150 mm |
| Work area width (X) | 110 mm | 150 mm |
| Work area depth (Y) | 110 mm | 150 mm |
| Work area (surface) | 121 cm² | 225 cm² |
| Speed & cutting | ||
| Max engraving / travel speed | 15,000 mm/s | 10,000 mm/s |
| Precision | ||
| Positioning accuracy | — | 0.01 mm |
| Safety | ||
| Enclosed (fully covered) | No | No |
| Features | ||
| Built-in camera | No | No |
| Autofocus / auto height | Yes | Yes |
| Rotary attachment support | Yes | Yes |
| Water cooling | Yes | — |
| Connectivity & software | ||
| Connections | USB | USB |
| USB | Yes | Yes |
| Compatible software | LightBurn, EZCAD3 | LightBurn |
| LightBurn compatible | Yes | Yes |
| Size & power | ||
| Weight | — | 34 kg |
| Rated power consumption | 615 W | — |
