AtomStack A10 Pro V2 vs Genmitsu Kiosk 5W
What A10 Pro V2 does better (6) and where Kiosk 5W wins (3) — every spec side by side.
vs
6.3Power & cutting3.2
6.1Speed4.4
5.5Precision7.6
7.1Work area2.7
6.4Safety2.1
4.0Features & ease of use7.4
Dimensions
Size comparison
A10 Pro V2Kiosk 5W
| A10 Pro V2 | Kiosk 5W | Difference | |
|---|---|---|---|
| Height | 178 mm | 220 mm | −42 mm |
| Width | 178 mm | 235 mm | −57 mm |
| Depth | 254 mm | 280 mm | −26 mm |
| Weight | 6 kg | 2.8 kg | +3.2 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is A10 Pro V2 better than Kiosk 5W?
- Work area (surface)1,558 cm² vs 100 cm²15.6×
- Laser output power10 W vs 5 W2×
- Max engraving / travel speed400 mm/s vs 200 mm/s2×
- Work area width (X)410 mm vs 100 mm4.1×
- Work area depth (Y)380 mm vs 100 mm3.8×
- Flame / fire detectionYes · Kiosk 5W: No
Why is Kiosk 5W better than A10 Pro V2?
- Positioning accuracy0.02 mm vs 0.01 mm2×
- Air assistNo · A10 Pro V2: Yes
- Weight6 kg vs 2.8 kg2.1×
Specifications
Side by side
| General | ||
| Laser sources | Blue diode (≈455 nm) | Blue diode (≈455 nm) |
| Motion system | Gantry (XY rails) | Gantry (XY rails) |
| Two laser sources | No | No |
| Wavelength | 455 nm | — |
| Laser power | ||
| Laser output power | 10 W | 5 W |
| Work area | ||
| Work area | 410 × 380 mm | 100 × 100 mm |
| Work area width (X) | 410 mm | 100 mm |
| Work area depth (Y) | 380 mm | 100 mm |
| Work area (surface) | 1,558 cm² | 100 cm² |
| Max workpiece height | — | 70 mm |
| Speed & cutting | ||
| Max engraving / travel speed | 400 mm/s | 200 mm/s |
| Max cutting depth – wood / plywood (one pass) | 12 mm | — |
| Max cutting depth – acrylic | 10 mm | — |
| Precision | ||
| Laser spot size | 0.08 mm | — |
| Positioning accuracy | 0.02 mm | 0.01 mm |
| Safety | ||
| Enclosed (fully covered) | No | No |
| Flame / fire detection | Yes | No |
| Emergency stop button | — | No |
| Tilt / movement sensor | — | Yes |
| Features | ||
| Air assist | No | Yes |
| Built-in camera | No | No |
| Autofocus / auto height | No | No |
| Rotary attachment support | Yes | Yes |
| Connectivity & software | ||
| Connections | USB, Wi-Fi | USB, Wi-Fi, SD / USB drive |
| Wi-Fi | Yes | Yes |
| USB | Yes | Yes |
| SD / TF card | — | Yes |
| Compatible software | LightBurn, LaserGRBL, AtomStack Studio | LightBurn, LaserGRBL |
| LightBurn compatible | Yes | Yes |
| File formats | JPG, SVG, PNG, BMP, PDF, G-code, DXF | — |
| Size & power | ||
| Width | 178 mm | 235 mm |
| Depth | 254 mm | 280 mm |
| Height | 178 mm | 220 mm |
| Weight | 6 kg | 2.8 kg |
| Rated power consumption | 50 W | — |
