OMTech Maker AF4063-150 150W
OMTech Maker AF4063-150 150W is a CO2 laser cutter released in 2023. Key specs: laser sources CO2 (10.6 µm), laser output power 150 W, work area 1016 × 1600 mm, max engraving / travel speed 600 mm/s.
8.9Score
Power & cutting9.5
Speed5.8
Work area9.6
Safety9.2
Features & ease of use2.4
price rangeUS$5,900–7,300
- Year
- 2023
- Type
- CO2 laser cutter
- Brand
OMTech- Popularity
- #216 of 406
CO2 (10.6 µm)Laser sources
150 WLaser output power
1016 × 1600 mmWork area
600 mm/sMax engraving / travel speed
YesEnclosed (fully covered)
Spec guide
How it ranks among CO2 laser cutters of 2023
Compared with CO2 laser cutters released in 2023. Bars show the share of models it beats.
compared with other CO2 laser cutters
Why is Maker AF4063-150 150W a good choice?
Work area (surface): 16,256 cm²better than 96% of CO2 laser cutters
Laser output power: 150 Wbetter than 95% of CO2 laser cutters
Weak points
Max engraving / travel speed: 600 mm/sworse than 77% of CO2 laser cutters
Specifications
Full specifications
Laser power
- Laser output power
- 150 W
Work area
- Work area
- 1016 × 1600 mm
- Work area width (X)
- 1,016 mm
- Work area depth (Y)
- 1,600 mm
- Work area (surface)
- 16,256 cm²
- Pass-through slot
- Yes
Speed & cutting
- Max engraving / travel speed
- 600 mm/s
Safety
- Enclosed (fully covered)
- Yes
- Flame / fire detection
- Yes
Features
- Built-in camera
- No
- Autofocus / auto height
- No
- Rotary attachment support
- Yes
- Water cooling
- Yes
Connectivity & software
- Connections
- USB, Ethernet
- Wi-Fi
- No
- USB
- Yes
- Ethernet (LAN)
- Yes
- File formats
- AI, BMP, DXF, GIF, HPGL, JPG, PDF, PLT, PNG, SVG, TIFF
Size & power
- Width
- 2,200 mm
- Depth
- 1,539 mm
- Height
- 960 mm
- Weight
- 370.1 kg
- Rated power consumption
- 150 W
Specs are collected from manufacturers and open databases and normalised to one format; check details with the seller before you buy.
