GenmitsuDiode laser engraver
Genmitsu Kortek 5W
Genmitsu Kortek 5W is a diode laser engraver released in 2025. Key specs: laser sources Blue diode (≈455 nm), Infrared diode (1064 nm), laser output power 5 W, work area 150 × 200 mm, max engraving / travel speed 117 mm/s.
4.4Score
Power & cutting3.2
Speed2.6
Work area4.2
Safety8.3
Features & ease of use7.4
price rangeUS$110–140
- Year
- 2025
- Brand
- Genmitsu
- Popularity
- #82 of 406
Blue diode (≈455 nm), Infrare…Laser sources
5 WLaser output power
150 × 200 mmWork area
117 mm/sMax engraving / travel speed
YesEnclosed (fully covered)
Class 1 (eye-safe, enclosed)Laser safety class
Spec guide
How it ranks among diode laser engravers of 2025
Compared with diode laser engravers released in 2025. Bars show the share of models it beats.
Specifications
Full specifications
General
- Motion system
- Gantry (XY rails)
- Two laser sources
- No
- Wavelength
- 455 nm
Laser power
- Laser output power
- 5 W
Work area
- Work area
- 150 × 200 mm
- Work area width (X)
- 150 mm
- Work area depth (Y)
- 200 mm
- Work area (surface)
- 300 cm²
- Max workpiece height
- 60 mm
Speed & cutting
- Max engraving / travel speed
- 117 mm/s
Safety
- Enclosed (fully covered)
- Yes
- Flame / fire detection
- No
- Laser shield / filter cover
- Yes
Features
- Air assist
- Yes
- Built-in camera
- No
- Autofocus / auto height
- No
- Rotary attachment support
- Yes
Connectivity & software
- Connections
- USB, Wi-Fi
- Wi-Fi
- Yes
- USB
- Yes
- Phone app control
- Yes
Size & power
- Rated power consumption
- 60 W
Specs are collected from manufacturers and open databases and normalised to one format; check details with the seller before you buy.
