- Pro FLUX Flying 100W vs Pro Quantum RF 60W
OMTech Pro FLUX Flying 100W vs OMTech Pro Quantum RF 60W
What Pro FLUX Flying 100W does better (1) and where Pro Quantum RF 60W wins (5) — every spec side by side.
vs
8.3Power & cutting4.9
6.8Precision9.3
6.8Work area9.6
4.7Safety4.7
7.8Features & ease of use9.1
Dimensions
Size comparison
Pro FLUX Flying 100WPro Quantum RF 60W
| Pro FLUX Flying 100W | Pro Quantum RF 60W | Difference | |
|---|---|---|---|
| Height | 1,031 mm | 1,039 mm | −8 mm |
| Width | 1,811 mm | 1,610 mm | +201 mm |
| Depth | 1,290 mm | 1,240 mm | +50 mm |
Drawn to the same scale from the official dimensions (front and side).
Why is Pro FLUX Flying 100W better than Pro Quantum RF 60W?
- Laser output power100 W vs 60 W+67%
Why is Pro Quantum RF 60W better than Pro FLUX Flying 100W?
- Work area (surface)6,000 cm² vs 16,256 cm²2.7×
- Pass-through slotNo · Pro FLUX Flying 100W: Yes
- Wi-FiNo · Pro FLUX Flying 100W: Yes
- Work area depth (Y)600 mm vs 1,016 mm+69%
- Work area width (X)1,000 mm vs 1,600 mm+60%
Specifications
Side by side
| General | ||
| Laser sources | CO2 (10.6 µm) | CO2 (10.6 µm) |
| Motion system | Galvo (scanning mirrors) | Gantry (XY rails) |
| Two laser sources | No | No |
| Laser power | ||
| Laser output power | 100 W | 60 W |
| Work area | ||
| Work area | 1000 × 600 mm | 1600 × 1016 mm |
| Work area width (X) | 1,000 mm | 1,600 mm |
| Work area depth (Y) | 600 mm | 1,016 mm |
| Work area (surface) | 6,000 cm² | 16,256 cm² |
| Max workpiece height | 201 mm | — |
| Pass-through slot | No | Yes |
| Speed & cutting | ||
| Max engraving / travel speed | — | 600 mm/s |
| Precision | ||
| Laser spot size | — | 0.07 mm |
| Positioning accuracy | 0.01 mm | — |
| Safety | ||
| Enclosed (fully covered) | Yes | Yes |
| Exhaust fan | Yes | — |
| Features | ||
| Air assist | Yes | — |
| Built-in camera | Yes | Yes |
| Autofocus / auto height | Yes | Yes |
| Rotary attachment support | Yes | Yes |
| Touchscreen / control panel | Yes | — |
| Water cooling | Yes | Yes |
| Connectivity & software | ||
| Connections | USB, Ethernet | USB, Wi-Fi, Ethernet |
| Wi-Fi | No | Yes |
| USB | Yes | Yes |
| Ethernet (LAN) | Yes | Yes |
| Compatible software | — | RDWorks |
| File formats | — | AI, BMP, DXF, GIF, HPGL, JPG, PDF, PLT, PNG, SVG, TIFF |
| Size & power | ||
| Width | 1,811 mm | 1,610 mm |
| Depth | 1,290 mm | 1,240 mm |
| Height | 1,031 mm | 1,039 mm |
| Rated power consumption | — | 60 W |
| Input voltage | 110–120 V | — |
