OMTech Integrated 20W vs Sculpfun G20 20W
What Integrated 20W does better (0) and where G20 20W wins (1) — every spec side by side.
vs
2.7Power & cutting2.7
7.6Speed4.9
5.1Work area5.1
7.3Safety4.7
3.2Features & ease of use3.6
Dimensions
Size comparison
Integrated 20WG20 20W
| Integrated 20W | G20 20W | Difference | |
|---|---|---|---|
| Height | 550 mm | 418 mm | +132 mm |
| Width | 400 mm | 330 mm | +70 mm |
| Depth | 340 mm | 250 mm | +90 mm |
| Weight | 16.5 kg | 6.9 kg | +9.6 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is Integrated 20W better than G20 20W?
Integrated 20W has no measurable advantages in this pair.
Why is G20 20W better than Integrated 20W?
- Weight16.5 kg vs 6.9 kg2.4×
Specifications
Side by side
| General | ||
| Laser sources | Fibre (1064 nm) | Fibre (1064 nm) |
| Motion system | Galvo (scanning mirrors) | Galvo (scanning mirrors) |
| Two laser sources | No | No |
| Wavelength | 1,064 nm | 1,064 nm |
| Frame material | Aluminium | — |
| Laser power | ||
| Laser output power | 20 W | 20 W |
| Work area | ||
| Work area | 150 × 150 mm | 150 × 150 mm |
| Work area width (X) | 150 mm | 150 mm |
| Work area depth (Y) | 150 mm | 150 mm |
| Work area (surface) | 225 cm² | 225 cm² |
| Work-area extension kit | — | Yes |
| Speed & cutting | ||
| Max engraving / travel speed | 10,008 mm/s | 10,000 mm/s |
| Precision | ||
| Positioning accuracy | 0.01 mm | — |
| Safety | ||
| Enclosed (fully covered) | No | No |
| Built-in fume filter / purifier | Yes | — |
| Features | ||
| Built-in camera | No | No |
| Autofocus / auto height | No | No |
| Rotary attachment support | Yes | Yes |
| Touchscreen / control panel | Yes | — |
| Connectivity & software | ||
| Connections | USB | USB, Wi-Fi |
| Wi-Fi | — | Yes |
| USB | Yes | Yes |
| Phone app control | — | Yes |
| Compatible software | LightBurn | LightBurn |
| LightBurn compatible | Yes | Yes |
| File formats | BMP, GIF, JPG, DXF, DST, AI | SVG, DXF, JPG, PNG, BMP |
| Size & power | ||
| Width | 400 mm | 330 mm |
| Depth | 340 mm | 250 mm |
| Height | 550 mm | 418 mm |
| Weight | 16.5 kg | 6.9 kg |
| Rated power consumption | 50 W | — |
