Monport 10W Pro vs Monport 2D Inner 10W
What 10W Pro does better (0) and where 2D Inner 10W wins (1) — every spec side by side.
vs
7.8Power & cutting7.8
8.5Speed8.5
7.5Precision7.5
6.4Work area6.4
3.0Safety3.0
3.2Features & ease of use3.2
Dimensions
Size comparison
10W Pro2D Inner 10W
| 10W Pro | 2D Inner 10W | Difference | |
|---|---|---|---|
| Height | 546 mm | 545 mm | +1 mm |
| Width | 290 mm | 290 mm | = |
| Depth | 500 mm | 500 mm | = |
| Weight | 16.5 kg | 15.6 kg | +0.9 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is 10W Pro better than 2D Inner 10W?
10W Pro has no measurable advantages in this pair.
Why is 2D Inner 10W better than 10W Pro?
- Weight16.5 kg vs 15.6 kg+6%
Specifications
Side by side
| General | ||
| Laser sources | UV (355 nm) | UV (355 nm) |
| Motion system | Galvo (scanning mirrors) | Galvo (scanning mirrors) |
| Two laser sources | No | No |
| Wavelength | 355 nm | 355 nm |
| Laser power | ||
| Laser output power | 10 W | 10 W |
| Work area | ||
| Work area | 150 × 150 mm | 150 × 150 mm |
| Work area width (X) | 150 mm | 150 mm |
| Work area depth (Y) | 150 mm | 150 mm |
| Work area (surface) | 225 cm² | 225 cm² |
| Speed & cutting | ||
| Max engraving / travel speed | 15,001 mm/s | 15,001 mm/s |
| Precision | ||
| Positioning accuracy | 0.001 mm | 0.001 mm |
| Safety | ||
| Enclosed (fully covered) | No | No |
| Laser safety class | Class 4 (open beam) | Class 4 (open beam) |
| Features | ||
| Built-in camera | No | No |
| Autofocus / auto height | No | No |
| Rotary attachment support | Yes | Yes |
| Water cooling | Yes | Yes |
| Connectivity & software | ||
| Connections | USB | USB |
| USB | Yes | Yes |
| Compatible software | LightBurn | LightBurn |
| LightBurn compatible | Yes | Yes |
| File formats | PNG, BMP, JPG, DXF, PLT, AI, SVG, STL | BMP, JPG, PNG, GIF, TIF, TIFF |
| Size & power | ||
| Width | 290 mm | 290 mm |
| Depth | 500 mm | 500 mm |
| Height | 546 mm | 545 mm |
| Weight | 16.5 kg | 15.6 kg |
| Rated power consumption | 400 W | — |
| Input voltage | 110–120 V | — |
