- Kintix Hybrid 10W vs Ray7 15W
Genmitsu Kintix Hybrid 10W vs Longer Ray7 15W
What Kintix Hybrid 10W does better (4) and where Ray7 15W wins (6) — every spec side by side.
vs
5.7Power & cutting7.0
9.5Speed8.0
7.2Precision5.7
3.7Work area5.3
7.4Safety6.9
6.2Features & ease of use6.9
Why is Kintix Hybrid 10W better than Ray7 15W?
- Max engraving / travel speed1,500 mm/s vs 600 mm/s2.5×
- Enclosed (fully covered)Yes · Ray7 15W: No
- Positioning accuracy0.01 mm vs 0.06 mm6×
- Autofocus / auto heightYes · Ray7 15W: No
Why is Ray7 15W better than Kintix Hybrid 10W?
- Work area (surface)200 cm² vs 946 cm²4.7×
- Laser output power10 W vs 15 W+50%
- Air assistNo · Kintix Hybrid 10W: Yes
- Work area depth (Y)100 mm vs 310 mm3.1×
- Flame / fire detectionNo · Kintix Hybrid 10W: Yes
- Work area width (X)200 mm vs 305 mm+52%
Specifications
Side by side
| General | ||
| Laser sources | Blue diode (≈455 nm) | Blue diode (≈455 nm) |
| Motion system | Galvo (scanning mirrors) | Gantry (XY rails) |
| Two laser sources | No | No |
| Wavelength | 455 nm | — |
| Laser power | ||
| Laser output power | 10 W | 15 W |
| Work area | ||
| Work area | 200 × 100 mm | 305 × 310 mm |
| Work area width (X) | 200 mm | 305 mm |
| Work area depth (Y) | 100 mm | 310 mm |
| Work area (surface) | 200 cm² | 946 cm² |
| Speed & cutting | ||
| Max engraving / travel speed | 1,500 mm/s | 600 mm/s |
| Precision | ||
| Laser spot size | — | 0.06 mm |
| Positioning accuracy | 0.01 mm | 0.06 mm |
| Linear rails | Yes | — |
| Safety | ||
| Enclosed (fully covered) | Yes | No |
| Laser safety class | Class 1 (eye-safe, enclosed) | — |
| Flame / fire detection | No | Yes |
| Emergency stop button | Yes | Yes |
| Lid interlock | Yes | — |
| Features | ||
| Air assist | No | Yes |
| Built-in camera | No | No |
| Autofocus / auto height | Yes | No |
| Offline engraving (no computer) | Yes | Yes |
| Connectivity & software | ||
| Connections | USB, Wi-Fi, SD / USB drive | Wi-Fi |
| Wi-Fi | Yes | Yes |
| USB | Yes | — |
| SD / TF card | Yes | — |
| Phone app control | Yes | — |
| Compatible software | LightBurn | — |
| LightBurn compatible | Yes | — |
| File formats | JPG, BMP, PNG, SVG, DXF, PLT, HPGL | — |
| Size & power | ||
| Rated power consumption | 60 W | — |
