- Hurricane 55W vs Maker AF2028-60 60W
AtomStack Hurricane 55W vs OMTech Maker AF2028-60 60W
What Hurricane 55W does better (4) and where Maker AF2028-60 60W wins (4) — every spec side by side.
vs
5.7Power & cutting4.9
5.8Speed5.8
4.4Work area5.6
8.3Safety4.7
8.7Features & ease of use4.1
Dimensions
Size comparison
Hurricane 55WMaker AF2028-60 60W
| Hurricane 55W | Maker AF2028-60 60W | Difference | |
|---|---|---|---|
| Height | 235 mm | 930 mm | −695 mm |
| Width | 1,042 mm | 1,199 mm | −157 mm |
| Depth | 695 mm | 871 mm | −176 mm |
| Weight | 59 kg | 112.9 kg | −53.9 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is Hurricane 55W better than Maker AF2028-60 60W?
- Built-in cameraYes · Maker AF2028-60 60W: No
- Autofocus / auto heightYes · Maker AF2028-60 60W: No
- Wi-FiYes · Maker AF2028-60 60W: No
- Weight59 kg vs 112.9 kg+91%
Why is Maker AF2028-60 60W better than Hurricane 55W?
- Work area (surface)1,500 cm² vs 2,477 cm²+65%
- Laser output power55 W vs 60 W+9%
- Work area depth (Y)300 mm vs 406 mm+35%
- Work area width (X)500 mm vs 610 mm+22%
Specifications
Side by side
| General | ||
| Laser sources | CO2 (10.6 µm) | CO2 (10.6 µm) |
| Motion system | Gantry (XY rails) | Gantry (XY rails) |
| Two laser sources | No | No |
| Wavelength | 10,600 nm | — |
| Laser power | ||
| Laser output power | 55 W | 60 W |
| Work area | ||
| Work area | 500 × 300 mm | 610 × 406 mm |
| Work area width (X) | 500 mm | 610 mm |
| Work area depth (Y) | 300 mm | 406 mm |
| Work area (surface) | 1,500 cm² | 2,477 cm² |
| Pass-through slot | Yes | Yes |
| Conveyor / roll feeder support | Yes | — |
| Speed & cutting | ||
| Max engraving / travel speed | 600 mm/s | 600 mm/s |
| Max cutting depth – wood / plywood (one pass) | 18 mm | — |
| Max cutting depth – acrylic | 20 mm | — |
| Precision | ||
| Linear rails | — | Yes |
| Safety | ||
| Enclosed (fully covered) | Yes | Yes |
| Laser safety class | Class 1 (eye-safe, enclosed) | — |
| Flame / fire detection | Yes | — |
| Emergency stop button | Yes | — |
| Tilt / movement sensor | Yes | — |
| Built-in fume filter / purifier | Yes | — |
| Exhaust fan | — | Yes |
| Features | ||
| Air assist | Yes | Yes |
| Built-in camera | Yes | No |
| Autofocus / auto height | Yes | No |
| Rotary attachment support | — | Yes |
| Touchscreen / control panel | — | Yes |
| Water cooling | — | Yes |
| Connectivity & software | ||
| Connections | USB, Wi-Fi | USB, Ethernet |
| Wi-Fi | Yes | No |
| USB | Yes | Yes |
| Ethernet (LAN) | — | Yes |
| Compatible software | LightBurn, AtomStack Studio | RDWorks |
| LightBurn compatible | Yes | — |
| File formats | — | AI, BMP, DXF, GIF, HPGL, JPG, PDF, PLT, PNG, SVG, TIFF |
| Size & power | ||
| Width | 1,042 mm | 1,199 mm |
| Depth | 695 mm | 871 mm |
| Height | 235 mm | 930 mm |
| Weight | 59 kg | 112.9 kg |
| Rated power consumption | — | 60 W |
