Aliencell X1 40W vs Ortur H20 40W
What X1 40W does better (4) and where H20 40W wins (0) — every spec side by side.
Why is X1 40W better than H20 40W?
- Work area (surface)2,910 cm² vs 1,260 cm²2.3×
- Flame / fire detectionYes · H20 40W: No
- Work area depth (Y)477 mm vs 300 mm+59%
- Work area width (X)610 mm vs 420 mm+45%
Why is H20 40W better than X1 40W?
H20 40W has no measurable advantages in this pair.
Specifications
Side by side
| General | ||
| Laser sources | Blue diode (≈455 nm) | Blue diode (≈455 nm), Infrared diode (1064 nm) |
| Motion system | Gantry (XY rails) | Gantry (XY rails) |
| Two laser sources | — | Yes |
| Wavelength | — | 1,064 nm |
| Frame material | — | Aluminium |
| Laser power | ||
| Laser output power | 40 W | 40 W |
| Second laser output power | — | 2 W |
| Work area | ||
| Work area | 610 × 477 mm | 420 × 300 mm |
| Work area width (X) | 610 mm | 420 mm |
| Work area depth (Y) | 477 mm | 300 mm |
| Work area (surface) | 2,910 cm² | 1,260 cm² |
| Max workpiece height | — | 98 mm |
| Speed & cutting | ||
| Max engraving / travel speed | — | 333 mm/s |
| Precision | ||
| Laser spot size | 0.1 mm | — |
| Safety | ||
| Enclosed (fully covered) | Yes | Yes |
| Laser safety class | Class 1 (eye-safe, enclosed) | Class 1 (eye-safe, enclosed) |
| Flame / fire detection | Yes | No |
| Emergency stop button | — | Yes |
| Tilt / movement sensor | — | Yes |
| Exhaust fan | — | Yes |
| Features | ||
| Air assist | Yes | Yes |
| Built-in camera | Yes | Yes |
| Autofocus / auto height | Yes | Yes |
| Rotary attachment support | Yes | — |
| Touchscreen / control panel | Yes | — |
| Connectivity & software | ||
| Connections | USB, Wi-Fi, Ethernet | USB, SD / USB drive |
| Wi-Fi | Yes | Yes |
| USB | Yes | Yes |
| Ethernet (LAN) | Yes | — |
| SD / TF card | — | Yes |
| Compatible software | LightBurn | LightBurn, LaserGRBL |
| LightBurn compatible | Yes | Yes |
| File formats | SVG, DXF, JPG, PNG, BMP | — |
| Size & power | ||
| Width | 903 mm | — |
| Depth | 787 mm | — |
| Height | 213 mm | — |
| Weight | 35 kg | — |
| Rated power consumption | 350 W | — |
