- Processing Talk
- Compare
- Alpha MK2 Extended 40W vs Falcon2 Pro S 40W
Algolaser Alpha MK2 Extended 40W vs Creality Falcon2 Pro S 40W
What Alpha MK2 Extended 40W does better (4) and where Falcon2 Pro S 40W wins (3) — every spec side by side.
vs
9.0Power & cutting9.0
2.3Precision3.2
7.0Work area5.5
Dimensions
Size comparison
Alpha MK2 Extended 40WFalcon2 Pro S 40W
| Alpha MK2 Extended 40W | Falcon2 Pro S 40W | Difference | |
|---|---|---|---|
| Height | 200 mm | 328 mm | −128 mm |
| Width | 692 mm | 664 mm | +28 mm |
| Depth | 585 mm | 570 mm | +15 mm |
| Weight | 8.4 kg | 27.9 kg | −19.5 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is Alpha MK2 Extended 40W better than Falcon2 Pro S 40W?
- Work area (surface)1,544 cm² vs 1,030 cm²+50%
- Weight8.4 kg vs 27.9 kg3.3×
- Work area depth (Y)386 mm vs 290 mm+33%
- Work area width (X)400 mm vs 355 mm+13%
Why is Falcon2 Pro S 40W better than Alpha MK2 Extended 40W?
- Autofocus / auto heightNo · Alpha MK2 Extended 40W: Yes
- Laser spot size0.175 mm vs 0.12 mm+46%
- Flame / fire detectionNo · Alpha MK2 Extended 40W: Yes
Specifications
Side by side
| General | ||
| Laser sources | Blue diode (≈455 nm) | Blue diode (≈455 nm) |
| Motion system | Gantry (XY rails) | Gantry (XY rails) |
| Two laser sources | No | — |
| Wavelength | 450 nm | 455 nm |
| Laser power | ||
| Laser output power | 40 W | 40 W |
| Work area | ||
| Work area | 400 × 386 mm | 355 × 290 mm |
| Work area width (X) | 400 mm | 355 mm |
| Work area depth (Y) | 386 mm | 290 mm |
| Work area (surface) | 1,544 cm² | 1,030 cm² |
| Work-area extension kit | Yes | — |
| Speed & cutting | ||
| Max engraving / travel speed | 333 mm/s | — |
| Precision | ||
| Laser spot size | 0.175 mm | 0.12 mm |
| Safety | ||
| Enclosed (fully covered) | No | — |
| Flame / fire detection | No | Yes |
| Emergency stop button | Yes | — |
| Built-in fume filter / purifier | Yes | — |
| Features | ||
| Air assist | Yes | — |
| Built-in camera | Yes | — |
| Autofocus / auto height | No | Yes |
| Rotary attachment support | Yes | — |
| Offline engraving (no computer) | Yes | — |
| Connectivity & software | ||
| Compatible software | LightBurn, LaserGRBL | LightBurn, LaserGRBL, Falcon Design Space |
| LightBurn compatible | Yes | Yes |
| Size & power | ||
| Width | 692 mm | 664 mm |
| Depth | 585 mm | 570 mm |
| Height | 200 mm | 328 mm |
| Weight | 8.4 kg | 27.9 kg |
| Input voltage | — | 100–240 V |
