Acmer S2 7W vs Genmitsu L8 20W
What S2 7W does better (1) and where L8 20W wins (7) — every spec side by side.
Dimensions
Size comparison
S2 7WL8 20W
| S2 7W | L8 20W | Difference | |
|---|---|---|---|
| Height | 195 mm | 261 mm | −66 mm |
| Width | 490 mm | 715 mm | −225 mm |
| Depth | 500 mm | 621 mm | −121 mm |
Drawn to the same scale from the official dimensions (front and side).
Why is S2 7W better than L8 20W?
- Laser spot size0.06 mm vs 0.13 mm2.2×
Why is L8 20W better than S2 7W?
- Laser output power7 W vs 20 W2.9×
- Max engraving / travel speed167 mm/s vs 667 mm/s4×
- Work area (surface)900 cm² vs 1,600 cm²+78%
- Enclosed (fully covered)No · S2 7W: Yes
- Built-in cameraNo · S2 7W: Yes
- Work area width (X)300 mm vs 400 mm+33%
- Work area depth (Y)300 mm vs 400 mm+33%
Specifications
Side by side
| General | ||
| Laser sources | Blue diode (≈455 nm) | Blue diode (≈455 nm) |
| Motion system | Gantry (XY rails) | Gantry (XY rails) |
| Two laser sources | No | No |
| Wavelength | — | 455 nm |
| Laser power | ||
| Laser output power | 7 W | 20 W |
| Work area | ||
| Work area | 300 × 300 mm | 400 × 400 mm |
| Work area width (X) | 300 mm | 400 mm |
| Work area depth (Y) | 300 mm | 400 mm |
| Work area (surface) | 900 cm² | 1,600 cm² |
| Speed & cutting | ||
| Max engraving / travel speed | 167 mm/s | 667 mm/s |
| Precision | ||
| Laser spot size | 0.06 mm | 0.13 mm |
| Positioning accuracy | — | 0.01 mm |
| Safety | ||
| Enclosed (fully covered) | No | Yes |
| Laser safety class | — | Class 1 (eye-safe, enclosed) |
| Flame / fire detection | No | No |
| Features | ||
| Air assist | Yes | Yes |
| Built-in camera | No | Yes |
| Autofocus / auto height | No | No |
| Rotary attachment support | Yes | Yes |
| Connectivity & software | ||
| Connections | — | Wi-Fi |
| Wi-Fi | — | Yes |
| USB | — | Yes |
| Compatible software | LightBurn | LightBurn |
| LightBurn compatible | Yes | Yes |
| File formats | — | JPG, BMP, PNG, GIF, DXF, PLT, HPGL |
| Size & power | ||
| Width | 490 mm | 715 mm |
| Depth | 500 mm | 621 mm |
| Height | 195 mm | 261 mm |
| Rated power consumption | — | 240 W |
