- P2 20W vs K1 Pro Max 48W
Acmer P2 20W vs Ikier K1 Pro Max 48W
What P2 20W does better (3) and where K1 Pro Max 48W wins (3) — every spec side by side.
vs
8.2Power & cutting9.3
9.2Work area8.5
6.0Safety6.7
5.0Features & ease of use7.9
Why is P2 20W better than K1 Pro Max 48W?
- Work area (surface)3,360 cm² vs 1,681 cm²+100%
- Work area depth (Y)800 mm vs 410 mm+95%
- Work area width (X)420 mm vs 410 mm+2%
Why is K1 Pro Max 48W better than P2 20W?
- Laser output power20 W vs 48 W2.4×
- Autofocus / auto heightNo · P2 20W: Yes
- Flame / fire detectionNo · P2 20W: Yes
Specifications
Side by side
| General | ||
| Laser sources | Blue diode (≈455 nm) | Blue diode (≈455 nm) |
| Motion system | Gantry (XY rails) | Gantry (XY rails) |
| Two laser sources | No | No |
| Wavelength | — | 455 nm |
| Laser power | ||
| Laser output power | 20 W | 48 W |
| Work area | ||
| Work area | 420 × 800 mm | 410 × 410 mm |
| Work area width (X) | 420 mm | 410 mm |
| Work area depth (Y) | 800 mm | 410 mm |
| Work area (surface) | 3,360 cm² | 1,681 cm² |
| Work-area extension kit | Yes | — |
| Speed & cutting | ||
| Max engraving / travel speed | — | 900 mm/s |
| Max cutting depth – wood / plywood (one pass) | 30 mm | 30 mm |
| Precision | ||
| Laser spot size | — | 0.2 mm |
| Positioning accuracy | — | 0.01 mm |
| Linear rails | Yes | Yes |
| Safety | ||
| Enclosed (fully covered) | No | No |
| Flame / fire detection | No | Yes |
| Emergency stop button | Yes | — |
| Tilt / movement sensor | Yes | Yes |
| Features | ||
| Air assist | Yes | Yes |
| Built-in camera | No | No |
| Autofocus / auto height | No | Yes |
| Rotary attachment support | — | Yes |
| Touchscreen / control panel | — | Yes |
| Offline engraving (no computer) | — | Yes |
| Connectivity & software | ||
| Connections | — | USB, Wi-Fi, SD / USB drive |
| Wi-Fi | — | Yes |
| USB | — | Yes |
| SD / TF card | — | Yes |
| Compatible software | LightBurn | LightBurn, LaserGRBL |
| LightBurn compatible | Yes | Yes |
| File formats | — | SVG, DXF, JPG, PNG, BMP, TIF |
| Size & power | ||
| Width | — | 780 mm |
| Depth | — | 500 mm |
| Height | — | 153 mm |
| Weight | — | 12 kg |
| Input voltage | — | 100–240 V |
